About the Drop Tower and Pendulum Facilities

The Drop Tower and Pendulum Facilities house three drop towers and multiple pendulums for use in under-vehicle blast acceleration and helmet impact testing.
Pendulum and Drop Tower Lab Image

Facility Equipment

Data Capture

Data Capture

Data in this facility is captured using several high-speed video cameras and digital data-acquisition systems capable of high-throughput data capture.
Drop Towers

Drop Towers

Two seven-meter-high drop towers are used to simulate under-vehicle blast accelerations to component systems using a custom-designed lever-arm mechanism and reaction tower decelerator. There is also a helmet testing drop tower that accommodates six-meter-per-second impacts.
Pendulums

Pendulums

Pendulums include a six-wire swinging mass pendulum that accommodates various mass sizes and a rigid-arm pendulum, both of which accomplish a ten-meter-per-second impact. Another custom-designed rigid-arm pendulum is used for various helmet impact testing, including football and military helmet evaluations.

For further information

Senior Engineer Michael Schlick, MS

Email Michael Schlick, MS

Senior Engineer Jason Moore, MS

Email Jason Moore, MS
